High Brightness Flexible Transparent LED Mesh Screen Display P40 P50 P55mm

Name: High Brightness Flexible Transparent LED Mesh Screen Display P40 P50 P55mm
Brand: CONWIN
Price: 1 USD

China High Brightness Flexible Transparent LED Mesh Screen Display P40 P50 P55mm wholesale

Brand Name : CONWIN

Model Number : M50

Certification : CE,ROHS

Place of Origin : China

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000sqm/month

Delivery Time : 5-8 working days

Packaging Details : wooden box or carton

Pitch : 50mm

Display Function : Video,picture,Outdoor,text,graphics

Power Per SQM : 12W

Weight Per SQM : 1.1KG

Protection Level : IP67

Life span : ≥1000000H

Power Supply : 110V~240V AC

Viewing Angle : 140 degree

Contact Now

Applications

High Brightness Flexible Transparent LED Mesh Screen Display P40 P50 P55mm

Products Description

High Brightness P40 P50 P55mm Flexible Transparent LED Mesh Screen Display Transparent LED Screen

1. Bigger diameter of the point light source to support power supply and signal transmission for longer distance.

2. Flexible installation method: the product has small size and light weight, with steel wire rope the installation methods are diverse.

3. Support uninterrupible transmission of dead pixels: even if one of the pixels damaged, the signal reception of subsequent pixels won 't be affeced, which will minimize the product faliure rate.

4. Multiple pixel pitches optional, to help save project cost.

Pixel Pitch	50mm	100mm
Pixel Density	400dot/㎡	100dot/㎡
Panel Size	W0.5*H2m/set / custom	W0.5*H2m /set / custom
Brightness	4500cd/㎡	2000cd/㎡
Max Power Consumption	72W/㎡	18W/㎡
Ave. Power Consumption	28.8W/㎡	7.2W/㎡
Transparency	80%	90%
Panel Weight	1kg/㎡	0.5kg/㎡
Unit Consumption	0.18W
Gray Scale	8bit/16bit
Waterproof Grade	IP67
Lifespan	≥50000H
Operating Temperature	-20°~ +50°
Storage Temperature	-40°~ +70°
Power Source	110V~220V
Input Voltage	5V
Viewing Angle	120°
TCP	WS2811/UCS1903
Warranty	2 Year

Details Images
