Indoor Glass Window Transparent LED Display Screen High Transparent Glass Ultra Thin LED Film P6 P8 P10 P16

Name: Indoor Glass Window Transparent LED Display Screen High Transparent Glass Ultra Thin LED Film P6 P8 P10 P16
Brand: CONWIN
Price: 1 USD

China Indoor Glass Window Transparent LED Display Screen High Transparent Glass Ultra Thin LED Film P6 P8 P10 P16 wholesale

Brand Name : CONWIN

Model Number : F4.81

Certification : CE,ROHS

Place of Origin : China

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 2000sqm/month

Delivery Time : 5-8 working days

Packaging Details : wooden box or carton

Transparency Rate : above 80%

Installation : Glass Paste Installation

Display Function : Video Picture Graphic Text Message

Contrast : 300:1Audio

Driver Chip : MBI 5024

Gray Scale : 14(bit)

Point Defect Rate : Three-tenths, divided into discrete

Scaning : 1/16

Powerinput Voltage : DC12V-2A

Led Lamps : DIP/SMT

Brightness Control : Manual / automatic adjustment

Installation Method : Hoisting / base / floor / fixed

Model Name : F4.8

Video Frame Rate : 60Hz

Resolution : 1080P 2K 4K

Contact Now

Product introduction

1.LED film screen is a high-end product that breaks the conventional LED display. Sunrise focuses on transparent display, innovates boldly, breaks the traditional thinking, and invests a lot in RESEARCH and development. It has the main control right from IC bare crystal structure and functional design, LED bracket, LED packaging and electronic circuit design. Currently has the world's leading return to zero code patent technology, dozens of film screen related inventions and practical patent technology, powerful technology to push transparent screen to a new height

2.Light (3 kg / ㎡), thin (3-6 mm), transparent, and arbitrary cut, joker modelling, beautiful atmosphere, simple installation is the biggest trend of countries better film screen, the better the development of film screen, is committed to meet the needs of global LED film screen, using our specific raw silicon chip, the components of solid loading on the high of PCB board, through the special cover process, The display module is integrated into an optical lens substrate with high transparency and luminescent display.

Indoor Glass Window Transparent LED Display Screen High Transparent Glass Ultra Thin LED Film P6 P8 P10 P16

Mode No.	F4*8	F5*10	F6	F6.5	F8	F10	F16
Module size(mm)	960x256	960x320	960x192	962X208	960x256	960x320	960x192
Transparent rate	55%	68%	50%	60%	65%	68%	75%
Film weight(Kg/㎡)	1~3	1~3	1~3	1~3	1~3	1~3	1~3
Film thickness(mm)	≤3	≤3	≤3	≤3	≤3	≤3	≤3
Pixel pitch(mm)	4X8	5X10	6X6	6.5X6.5	8X8	10X10	16X16
Pixel density(点/㎡)	31250	20000	27777	23716	15625	10000	3906
Brightness(cd/㎡)	1500-4500	1500-4500	1500-4500	1500-4500	1500-4500	1500-4500	1500-3000
Brightness scope	±0.003	±0.003	±0.003	±0.003	±0.003	±0.003	±0.003
View angle( °)	160	160	160	160	160	160	160
Pixel configure	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Rfresh rate(Hz)	≥1920	≥1920	≥1920	≥1920	≥1920	≥1920	≥1920
Averange power(w/㎡)	≤200	≤200	≤200	≤200	≤200	≤240	≤200
Max power(w/㎡)	≤600	≤600	≤600	≤600	≤600	≤800	≤600
Working temper.(℃)	-20℃-55℃	-20℃-55℃	-20℃-55℃	-20℃-55℃	-20℃-55℃	-20℃-55℃	-20℃-55℃
Working humidity(RH)	10%-90%	10%-90%	10%-90%	10%-90%	10%-90%	10%-90%	10%-90%
Dtive type	static	static	static	static	static	static	static
Control system	Novastar	Novastar	Novastar	Novastar	Novastar	Novastar	Novasta
